Products catalog - Temperature transmitters -S95.3Ux2 /138 HART SIL2

The prices are shown in the currency of the supplier, the prices in your selected currency will be displayed in the purchasing basket.
Please click on the 'Download' button at the bottom of the page if you wish to download a data sheet for this product.

Head mounted temperature transmitter
Characteristics :
- Instrument :
Temperature Transmitters

- Industry :
Chemical industry
Treatment of the water
Production of energy
Heater
Air conditioning
Ventilation
Shipbuilding
Engines diesel, every type of compressors
Industrial ovens
Installations of cover
Mechanical engineering industry
Petrochemistry
Textile industry, paint
Ovens of drying

Description :
Head mounted temperature transmitter
  • SIL2 declaration of conformity (IEC 61508:2000)
  • Input: Pt100 or thermocouples: K,J,N,T,E,R,S,T,B,L,U
  • Sensor connection type : 2, 3 or 4 wires circuit
  • Output : 4…20mA HART 2 wire technology
  • Configurable error current signal :
    high alarm value 22 mA,
    low alarm value 3.5 mA
  • with galvanic separation
  • measuring error : 0.1 °K
  • Continous sensor and self monitoring :
    supply voltage,
    monitoring, wire break and corrosion monitoring
  • Power supply : 24V DC
  • Ambient temperature : -40°C + 85°C
  • Execution : ATEX Ex i as option
Company : RUEGER
Sales Group : Temperature transmitters
Please register in order to see prices.
If you click on Configure button, please wait while the configurator loads.
