Head mounted temperature transmitter
|
Characteristics : - Instrument : Temperature Transmitters
- Industry : Chemical industry
Treatment of the water
Production of energy
Heater
Air conditioning
Ventilation
Shipbuilding
Engines diesel, every type of compressors
Industrial ovens
Installations of cover
Mechanical engineering industry
Petrochemistry
Textile industry, paint
Ovens of drying
|
Description : Head mounted temperature transmitter Input : Pt100/0°C, Thermocouples K,J,N,T,E,R,S,T,L,U Input functionality :1 or 2 sensors (e.g. 2 x Pt100 3 wires), Sensor backup/redundancy, Sensor drift monitoring Sensor connection type : 2, 3 or 4 wires circuit /2x2 wires or 2x 3 wires Output : 4…20mA HART 2 wires technology with configurable error current signal : high alarm value 22 mA or low alarm value 3.5 mA or PROFIBUS PA, Profile 3.01 or FONDATION Fieldbus H1, ITK Version 5.1 with galvanic separation Measuring error : 0.1 °K Continous sensor and self monitoring : supply voltage monitoring, wire break and corrosion monitoring Power supply : 24V DC Ambient temperature : -40°C + 85°C Options: Execution for SIL2 conformity, ATEX Exi certification, Ambient temperature : -50°C + 85°C
|
Company : RUEGER
|
Sales Group : Temperature transmitters
|
|
