Products catalog - Temperature transmitters -S95.4Wxx

The prices are shown in the currency of the supplier, the prices in your selected currency will be displayed in the purchasing basket.
Please click on the 'Download' button at the bottom of the page if you wish to download a data sheet for this product.

Field mounted temperature transmitter
Characteristics :
- Instrument :
Temperature Transmitters

- Industry :
Chemical industry
Treatment of the water
Production of energy
Air conditioning
Engines diesel, every type of compressors
Industrial ovens
Installations of cover
Mechanical engineering industry
Textile industry, paint
Ovens of drying

Description :

Field mounted temperature transmitter

  • Input : Pt100/0°C, Thermocouples KK,J,N,T,E,R,S,B,T,L,U
  • Input functionality : 1 or 2 sensors (e.g. 2 x Pt100 3 wires),
  • Sensor backup/redundancy, Sensor drift monitoring Sensor connection type : 2, 3 or 4 wires circuit / 2x2 wires or 2x 3 wires
  • Output : 4?20mA HART 2 wires technology,  PROFIBUS PA or Fieldbus
  • Configurable error current signal : high alarm value 22 mA, low alarm value 3.5 mA
  • Measuring error : 0.1 °K
  • with galvanic separation
  • Continous sensor and self monitoring : supply voltage monitoring, wire break and corrosion monitoring
  • Power supply : 24V DC Ambient temperature : -40°C + 85°C
  • Housing with or without display : aluminium die cast chromized inside/outside, 70mm, epoxide-coated, gray RAL9002 ; IP66 et IP 67 NEMA 4X or stainless steel
  • Execution : Execution for SIL2 conformity as option, ATEX Exi or Exd certification as option
Company : RUEGER
Sales Group : Temperature transmitters
Please register in order to see prices.
If you click on Configure button, please wait while the configurator loads.
